C-100 Reverse Osmosis System Control Panel
The dry contact switch inputs monitor storage tank level, low and high-pressure switch signal, and system lockout for pretreatment backwash or regeneration for on/off operation. All inputs and outputs are controlled with time delays for proper operation.
Additionally, the TDS value incorporates a field adjustable set point for the water quality threshold, allowing the unit to produce a system warning if the water quality threshold is exceeded. LED indicates water quality and operating status.
Features:
- Economical controls
- Visual status LED
- TDS monitor w/ sensor (range 0-1000 PPM)
- Three-digit LED display
- Jumper selectable flush type
- Jumper selectable switch inputs
- TDS calibration adjustment
- TDS setpoint adjustment
- Quick disconnect high voltage terminals
- Plug-in terminals for switch inputs
- Panel mountable enclosure
###
Specifications:
- Power: 120 VAC or 240 VAC - 15+10%, 50/60Hz
- Environment: -22F to 140F, 0-95%RH, Non-condensing
- Enclosure: 8.25”x5.0”x3.0” ABS plastic
###
Input/Output Switches:
- Low-pressure switch
- RO storage tank full
- Pretreatment Lockout (all switch inputs are jumped selectable NO or NC)
- Inlet solenoid valve 120/240 VAC 5 amp maximum
- RO pump 120/240 VAC 1HP, single phase maximum
- Flush solenoid valve 120/240 VAC 5 amp maximum
###
